![](https://it-infrastructure.solutions/content/images/2023/08/image-104.png)
This article has not been completed yet. However, it may already contain helpful Information and therefore it has been published at this stage
Info:
All log tables in Azure Monitor Logs must have a TimeGenerated
column populated with the timestamp of the logged event.
Var1 - Azure CLI:
![](https://it-infrastructure.solutions/content/images/2023/08/image-106.png)
Choose the bash mode.
az monitor log-analytics workspace table create --resource-group <Resource Group Name> --workspace-name <Workspace Name> -n <Tabel Name> --retention-time <Numer of Days> --columns <Column Name>=<Columntype> (e.g. Column1=string TimeGenerated=datetime)
![](https://it-infrastructure.solutions/content/images/2023/08/image-108.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-109.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-118.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-119.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-111.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-110.png)
Var2 - PowerShell:
![](https://it-infrastructure.solutions/content/images/2023/08/image-106.png)
Choose the PowerShell mode.
$tableParams = @'
{
"properties": {
"schema": {
"name": "TEST2_CL",
"columns": [
{
"name": "TimeGenerated",
"type": "DateTime"
},
{
"name": "TestColumn2",
"type": "String"
}
]
}
}
}
'@
Invoke-AzRestMethod -Path "/subscriptions/{subscription}/resourcegroups/{resourcegroup}/providers/microsoft.operationalinsights/workspaces/{workspace}/tables/MyTable_CL?api-version=2021-12-01-preview" -Method PUT -payload $tableParams
![](https://it-infrastructure.solutions/content/images/2023/08/image-112.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-118.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-119.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-113.png)
![](https://it-infrastructure.solutions/content/images/2023/08/2023-08-31-16_07_15-TEST2_CL---Microsoft-Azure-und-7-weitere-Seiten---Profil-1---Microsoft--Edge.png)
Var3 - Azure Portal:
Data Collection Endpoint:
![](https://it-infrastructure.solutions/content/images/2023/08/image-117.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-120.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-121.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-122.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-123.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-124.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-125.png)
Custom Log Table:
![](https://it-infrastructure.solutions/content/images/2023/08/image-118.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-119.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-114.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-115.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-116.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-126.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-127.png)
[
{
"TimeGenerated": "2014-11-08 15:55:55",
"TestColumn3": "Irgendein Text"
}
]
![](https://it-infrastructure.solutions/content/images/2023/08/image-128.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-129.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-130.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-131.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-132.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-133.png)
![](https://it-infrastructure.solutions/content/images/2023/08/image-134.png)
Additional helpful material:
Often you need a table, which matches the SYSLOG - table schematically.
Here you can find a script, with which you can create the table automatically.
$tableParams = @'
{
"properties": {
"schema": {
"name": "Syslog_CL",
"columns": [
{
"name": "MG",
"type": "guid",
"isHidden": true
},
{
"name": "SeverityLevel",
"type": "string",
"description": "Severity level of the event."
},
{
"name": "ProcessID",
"type": "int",
"description": "ID of the process that generated the message."
},
{
"name": "ProcessName",
"type": "string",
"description": "Name of the process that generated the message."
},
{
"name": "ManagementGroupName",
"type": "string"
},
{
"name": "HostName",
"type": "string",
"description": "Name of the system sending the message."
},
{
"name": "HostIP",
"type": "string",
"description": "IP address of the system sending the message."
},
{
"name": "SourceSystem",
"type": "string",
"description": "Type of agent the data was collected from. For syslog the value is typically Linux."
},
{
"name": "SyslogMessage",
"type": "string",
"description": "Text of the message."
},
{
"name": "TimeGenerated",
"type": "datetime",
"description": "Date and time the record was created."
},
{
"name": "TimeCollected",
"type": "datetime",
"isHidden": true
},
{
"name": "Computer",
"type": "string",
"description": "Computer that the event was collected from."
},
{
"name": "CollectorHostName",
"type": "string",
"description": "Name of the remote device that generated the message."
},
{
"name": "EventTime",
"type": "datetime",
"description": "Date and time that the event was generated."
},
{
"name": "Facility",
"type": "string",
"description": "The part of the system that generated the message."
}
]
}
}
}
'@
Invoke-AzRestMethod -Path "/subscriptions/{subscription}/resourcegroups/{resourcegroup}/providers/microsoft.operationalinsights/workspaces/{workspace}/tables/Syslog_CL?api-version=2021-12-01-preview" -Method PUT -payload $tableParams
![](https://it-infrastructure.solutions/content/images/2023/10/image-1.png)
More tables - templates, can be found here:
- CommonSecurityLog to BasicCommonSecLog
- SecurityEvent to BasicSecurityEvent
- Syslog to BasicSyslog
- Event to BasicEvent
